.: HyperFlea |
|
|
|
|
|
|
|
|
| The Hyperflea is a
delta wing made almost entirely out of high density EPP foam. It can be
bent, folder, or twisted and it will return to its normal shape. The only
adhesives I used were Goop for the firewall, and hotglue on everything else.
I even used hot glue on the hinges! |
|
|
|
|
|
|
|
|
|
| Here is a video of
the HyperFlea. You must have Windows
Media Player in order to view them. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| TYPE: |
EPP Delta Wing |
| MANUFACTURER: |
SuperFlyRC |
| ENGINE: |
Emax CF2805 |
| SPEED CONTROL |
THUNDERBIRD 18 |
Prop |
APC 6 x 4E |
|
WINGSPAN: |
22 in. |
| WEIGHT |
7.9 oz. |
|
WING AREA: |
450 sq. in. |
| WING LOADING: |
2.75 oz/sq. ft |
| LENGTH: |
18.75 in. |
| RADIO: |
2.4 ghz Futaba 8UAF w/ 2 micro servos
Spektrum 6100e |
|
|
|
|
|
|
|
|
 |
|
|
|
|
|
|
|
|
The HyperFlea
flying in a park by my school. |
|
|
|
|
 |
Looks a bit like the
F22 flying just above the tree tops. |
|
|
|
|
| |
|
|
|
|
|
